METTLER TOLEDO – Weighbridges
In the fast-paced world of logistics and transportation, every kilogram counts. Operations are often hampered by long lines at the scales, inaccurate data, or inflated maintenance costs due to extreme weather. It's time to turn to a vehicle weighing solution designed for limitless performance.
METTLER TOLEDO offers weighbridge and rail scale systems that are more than just measuring tools, but long-term investments. The VTS202 series is optimally designed for heavy highway traffic, while the VTS302 is a formidable beast for overloaded vehicles on private roads or mining areas. Through "Module Tester" testing, which simulates 20 years of use in a short period of time, this product has proven capable of handling up to 250 fully loaded trucks daily without structural failure.
Its main advantage lies in its maximum rust protection through a shot-blasting process and a temperature-cured acrylic polyurethane paint. Not only is it tough on the outside, the embedded POWERCELL® technology ensures that the scale maintains accuracy even under lightning strikes of up to 100,000 Amperes.
Key Features:
• Orthotropic Design: Eliminates the weaknesses of traditional I-beam structures and provides exceptional torsional rigidity.
• Extreme Lightning Protection: Tested up to 100,000V and 80,000A (on the POWERCELL PDX model).
• Mechanical Checking System: The checker is mounted on the foundation, not the load cell, preventing sensor damage.
• Containerized Design: The module fits into a standard container to minimize shipping costs.
• Easy Maintenance Access: Equipped with an easily removable access plate for routine cleaning and servicing.
Applications:
• VTS202: Suitable for highway logistics operations with standard axle loads (up to 28t).
• VTS302: Specifically designed for heavy-duty vehicles on private roads/mining operations with extreme axle loads (up to 40t).
• Corrosive Environments: Ideal for areas with severe weather thanks to its RoHS-compliant protective paint.
For further information, please contact: PT Hyprowira Adhitama, METTLER TOLEDO's distributor in Indonesia. Please see this brochure for details.
